Prekinis ženklas
Gamintojo detalės numeris
PR1US540
Garantija
?
24 mėn.
EAN
4779051840632
Teltonika 5G Mobile SMA Antenna
Certified Teltonika Engineers
Official Teltonika Distributor
turime
?
4.30 €
4.30 €
Certified Teltonika Engineers
Official Teltonika Distributor
Smulkus aprašymas
Techninės specifikacijos
Suderinami produktai
Specifikacijos
Mobilusis Tinklas
Mobiliojo tinklo generavimas
5G (NR)
Antena
Antenos Dizainas
Omni
Mobiliosios Antenos Dažnių Diapazonas Ir Stiprinimas
0.617 - 0.960 (GHz) 4.5 (dBi), 1.41 - 1.61 (GHz) 4.5 (dBi), 1.71 - 2.69 (GHz) 4.5 (dBi), 3.3 - 7.125 (GHz) 4.5 (dBi)
Poliarizacija
Linijinis
VSWR
< 3
Varža
50 Ω
Jungtis
RF jungtys
(1) SMA Male
Fiziniai Parametrai
Spalva
Juoda
Apsaugos nuo patekimo kodas
IP33
Svoris
0.024 kg
Darbinė temperatūra
-40 °C iki 85 °C
Aplinka
Vidaus
Montavimo būdas
Varžtas
Pakuotėje Yra
Vienetai
1 vnt
